Black Water Pipe PE:
Material: PE80 PE100
Pressure Rating:
SDR26-0.6Mpa
SDR21-0.8Mpa
SDR17-1.0Mpa
SDR13.6-1.25Mpa
SDR11-0.6Mpa
Size: 16mm~1600mm
Standard: GB/T13663-2000, IS04427-2007
Colors: Black with blue stripes, other colors are available upon request.
Advantages
• Non-toxic: No heavy metal additives, dirt, or secondary pollution caused by a bacterium.
• Corrosion Resistant: Resist chemical mediator corrosion and electron chemical corrosion.
• Low Flow Resistance: A smooth inner wall and low friction produce low flow resistance and high volume.
• Excellent Flexibility: Can be coiled.
• Easy Installation: Lightweight and can be carried and installed easily.
• Long service life: More than 50 years.
• Various connection types: Butt fusion joint, electrofusion joint.
• Recycled and environmental-friendly
| Nominal OD | Maximum average OD | Material | SDR17 | SDR13.6 | SDR11 | SDR9 | ||||
| Grade | ||||||||||
| PE100 | 1MPa | 1.25MPa | 1.6MPa | 2.0MPa | ||||||
| dnmm | Grade A | Ovality mm | Nominal Wall Thickness (mm) | Weight Per Meter | Nominal Wall Thickness (mm) | Weight Per Meter | Nominal Wall Thickness (mm) | Weight Per Meter | Nominal Wall Thickness (mm) | Weight Per Meter |
| mm | kg/m | kg/m | kg/m | kg/m | ||||||
| 16 | 16.3 | 1.2 | / | / | / | / | / | / | 2.3 | 0.105 |
| 20 | 20.3 | 1.2 | / | / | / | / | 2.3 | 0.136 | 2.3 | 0.136 |
| 25 | 25.3 | 1.2 | / | / | 2.3 | 0.174 | 2.3 | 0.174 | 3 | 0.219 |
| 32 | 32.3 | 1.3 | 2.3 | 0.228 | 2.4 | 0.237 | 3 | 0.285 | 3.6 | 0.336 |
| 40 | 40.4 | 1.4 | 2.4 | 0.301 | 3 | 0.365 | 3.7 | 0.441 | 4.5 | 0.523 |
| 50 | 50.4 | 1.4 | 3 | 0.463 | 3.7 | 0.563 | 4.6 | 0.684 | 5.6 | 0.811 |
| 63 | 63.4 | 1.5 | 3.8 | 0.738 | 4.7 | 0.896 | 5.8 | 1.08 | 7.1 | 1.294 |
| 75 | 75.5 | 1.6 | 4.5 | 1.041 | 5.6 | 1.27 | 6.8 | 1.509 | 8.4 | 1.818 |
| 90 | 90.6 | 1.8 | 5.4 | 1.497 | 6.7 | 1.819 | 8.2 | 2.186 | 10.1 | 2.623 |
| 110 | 110.7 | 2.2 | 6.6 | 2.228 | 8.1 | 2.695 | 10 | 3.242 | 12.3 | 3.897 |
| 125 | 125.8 | 2.5 | 7.4 | 2.841 | 9.2 | 3.472 | 11.4 | 4.206 | 14 | 5.026 |
| 140 | 140.9 | 2.8 | 8.3 | 3.567 | 10.3 | 4.348 | 12.7 | 5.242 | 15.7 | 6.314 |
| 160 | 161 | 3.2 | 9.5 | 4.656 | 11.8 | 5.676 | 14.6 | 6.881 | 17.9 | 8.222 |
| 180 | 181.1 | 3.6 | 10.7 | 5.889 | 13.3 | 7.203 | 16.4 | 8.697 | 20.1 | 10.402 |
| 200 | 201.2 | 4 | 11.9 | 7.267 | 14.7 | 8.835 | 18.2 | 10.725 | 22.4 | 12.863 |
| 225 | 226.4 | 4.5 | 13.4 | 9.218 | 16.6 | 11.219 | 20.5 | 13.575 | 25.2 | 16.281 |
| 250 | 251.5 | 5 | 14.8 | 11.296 | 18.4 | 13.82 | 22.7 | 16.695 | 27.9 | 20.009 |
| 280 | 281.7 | 9.8 | 16.6 | 14.191 | 20.6 | 17.316 | 25.4 | 20.93 | 31.3 | 25.152 |
| 315 | 316.9 | 11.1 | 18.7 | 17.971 | 23.2 | 21.947 | 28.6 | 26.494 | 35.2 | 31.819 |
| 355 | 357.2 | 12.5 | 21.1 | 22.873 | 26.1 | 27.826 | 32.2 | 33.634 | 39.7 | 40.413 |
| 400 | 402.4 | 14 | 23.7 | 28.906 | 29.4 | 35.286 | 36.3 | 42.699 | 44.7 | 51.262 |
| 450 | 452.7 | 14 | 26.7 | 36.623 | 33.1 | 44.696 | 40.9 | 54.069 | 50.3 | 64.905 |
| 500 | 503 | 17.5 | 29.7 | 45.251 | 36.8 | 55.151 | 45.4 | 66.717 | 55.8 | 79.978 |
| 560 | 563.4 | 19.6 | 33.2 | 56.689 | 41.2 | 69.193 | 50.8 | 83.581 | 62.5 | 100.345 |
| 630 | 633.8 | 22.1 | 37.4 | 71.799 | 46.3 | 87.457 | 57.2 | 105.898 | 70.3 | 126.977 |
| 710 | 716.4 | / | 42.1 | 91.246 | 52.2 | 111.287 | 64.5 | 134.743 | 79.3 | 161.656 |
| 800 | 807.2 | / | 47.4 | 115.702 | 58.8 | 141.164 | 72.6 | 170.878 | 89.3 | 205.11 |
| 900 | 908.1 | / | 53.3 | 146.359 | 66.2 | 178.837 | 81.7 | 216.296 | / | / |
| 1000 | 1009 | / | 59.3 | 180.886 | 72.5 | 217.817 | 90.2 | 265.555 | / | / |
| 1200 | 1210.8 | / | 67.9 | 249.158 | 88.2 | 317.618 | / | / | / | / |
| 1400 | 1412.6 | / | 82.4 | 351.918 | 102.9 | 432.131 | / | / | / | / |
| 1600 | 1614.4 | / | 94.1 | 459.337 | 117.6 | 564.446 | / | / | / | / |
| 1800 | 1816.2 | / | 105.9 | 581.288 | / | / | / | / | / | / |
| 2000 | 2018 | / | 117.6 | 717.308 | / | / | / | / | / | / |
| 2250 | 2270.3 | / | / | / | / | / | / | / | / | / |
| 2500 | 2522.5 | / | / | / | / | / | / | / | / | / |
